Northwood II
NW-1000
Bedrooms
2
Bathrooms
1
Square Feet
728
Dimensions
14' x 52'
Standard features and specifications
Exterior
- Colour coordinated metal fascia
- Vinyl siding and white vinyl soffit
- 16ʺ eave on HE; 12ʺ on long walls
- 4/12 pitch roof
- 30-year architectural fiberglass shingles
- 7/16" roof sheathing
- 2 Exterior GFI receptacles
- Separate receptacle for heat tape
- Engineered roof trusses to 2.8 kPa snow load
- 2" x 10" floor joists @ 16ʺ o.c.
- 3/8" wall sheathing on inside & outside of exterior walls
- Walls: R22 +R10 exterior rigid foam. R32 total
- R60 ceiling
- 14’ wide R32 floor. 16’ wide R38 floor
- 2x6 side walls at 24" o.c. - 8' walls
- 19/32" T&G subfloor
- Exterior Frost-free tap – kitchen sink
- 12" tubular steel frame with detachable hitch
Interior
- Decorative vinyl covered drywall (one colour throughout)
- 6 mil. vapour barrier includes switches and receptacles
- Quality vinyl floor throughout
- Cathedral ceilings in LR, DR, KIT
- Wire only ceiling light in living room
- Swirl light in dining room / Ceiling lights in all rooms
- Solid shelving in all closets
- Knob handles on all doors
- Factory select décor and lighting
- White hardboard passage doors 24"-30" (no profile)
- 4" ceramic tile backsplash at kitchen and vanities with tile edging
- 2x4 interior walls
- Vinyl wrap moulding throughout
Exterior Doors
- Insulated steel exterior doors, 36" front and rear (where possible) with peepholes and deadbolts
- Lever door handles
- Coach lights at all exterior doors
Windows
- Triple Glazed, Double Low E, Argon Filled & Tinted. Zone D C/A Window w Egress Hinge
- .98 U Value
Kitchen
- Adjustable shelf in all cabinets – (2) upper and (1) lower
- Double stainless-steel sink
- 15" bank of drawers
- PVC cabinet doors
- 2-speed range hood with light and fan vented to exterior
- 18 cu. ft. fridge
- 30" electric range
- White kitchen appliances
- Shelf over fridge
- 2 handle faucets
- Communication box (empty) at kitchen area
Bathrooms
- Exhaust fan with humidistat in main bath
- Exhaust fan in ensuite on separate switch
- Towel bar and towel ring (most models) in each bath
- Cosmetic box in main bath
- LUXURY SHOWER & RAINFALL SHWRHD
- Showerhead and shower rod in all baths
- GFI receptacle in all baths
- Walled tub/shower with single lever pressure balanced faucet in all baths
- 2 handle faucets in all baths
Utility Rooms
- HRV system (heating recovery ventilation)
- Plumbed and wired for washer/dryer
- High efficiency gas furnace
- Optional High efficiency oil furnace
- 100-amp electrical panel
- Electric hot water tank
- Shelf over washer/dryer area
- Dryer vent rough in
- Insulated lines in HWT cavity
Miscellaneous
- Electric smoke/CO detector(s)
- Main electrical conduit through floor
- Programmable thermostat
- Airtight Protocol
- LED Light bulb package
*This is not a fully detailed specification. Our factory reserves the right to change specifications, designs, materials and suppliers without notice and without incurring obligations. Homes shown and/or contained herein is from data available at time of printing.
